Hardware and Software#

Note

Source: Originally contributed by PhD students in COMP 501 at Loyola University Chicago. The Memory Hierarchy, Processes, and Types of Computer Systems sections draw on material from the companion Operating Systems and CS Curricula sites.

Every computer system is built on two inseparable layers: hardware, the physical components you can touch, and software, the instructions that tell the hardware what to do. Understanding both layers — and how they work together — gives you a mental model that will serve you throughout your programming career.

What Is Hardware?#

Hardware consists of the tangible components of a computer system. These components perform computation, store data, interact with the outside world, and support all of those functions.

The core hardware components are:

CPU (Central Processing Unit) — the “brain” of the computer. It executes instructions from software, performs calculations, and makes decisions.
Memory (RAM) — short-term, fast storage. RAM holds data and programs currently in use so the CPU can access them quickly. Its contents are lost when power is off.
Storage (SSD/HDD) — long-term storage for files, applications, and the operating system. Data persists even when the power is off.
Input devices — let data and commands enter the system. Examples: keyboard, mouse, touchscreen, camera, microphone.
Output devices — show or send results back to the user. Examples: monitor, printer, speakers.
Supporting hardware — power supplies, batteries, cooling fans, and network interfaces (USB, Wi-Fi) that keep the system stable and connected.

All major components are connected through the motherboard, which acts as the circulatory system of the computer, carrying power and signals between parts.

The Memory Hierarchy#

The hardware components that store data are not equal — they differ dramatically in speed and size. This tradeoff is captured by the memory hierarchy, a ladder that runs from the fastest (and smallest) storage to the slowest (and largest):

Registers — a handful of locations inside the CPU itself that hold the values being computed right now. Registers are the fastest storage that exists, but a typical processor has fewer than a hundred of them.
Cache — a small pool of high-speed memory (L1, L2, and L3 levels) built onto the processor chip. The CPU automatically copies recently used data here so it does not have to reach out to RAM every time.
RAM (main memory) — where your running program and all of its data live while the machine is on. Much larger than cache but noticeably slower.
SSD (solid-state drive) — flash-based secondary storage for files, databases, and the operating system at rest. Much faster than a spinning disk but still orders of magnitude slower than RAM.
HDD (hard disk drive) — traditional spinning magnetic storage offering large capacity at low cost, but with mechanical seek times that make it the slowest form of local storage in everyday use.
Tape — removable magnetic tape cartridges used for archival backups and long-term storage. Sequential access only; far cheaper per gigabyte than any disk, but retrieving data can take minutes.

The table below puts concrete numbers on these differences. Latencies are approximate and vary by hardware generation, but the ratios between levels are remarkably stable [DeanNorvig] [HennessyPatterson2024].

Approximate memory hierarchy latencies#
Level	Typical latency	Order of magnitude
Registers	< 1 ns	10⁰ ns
L1 cache	~1 ns	10⁰ ns
L2 cache	~4 ns	10⁰ ns
L3 cache	~15 ns	10¹ ns
RAM	~100 ns	10² ns
NVMe SSD	~100,000 ns (100 µs)	10⁵ ns
HDD	~10,000,000 ns (10 ms)	10⁷ ns
Tape	~10,000,000,000 ns (10 s)	10¹⁰ ns

Each level is roughly 10–100× slower than the one above it but offers far more capacity. When the CPU needs a value it checks the cache first, then RAM, and only falls back to storage as a last resort.

The memory hierarchy pyramid, showing registers at the top (fastest, smallest) down through cache, RAM, and disk storage at the bottom (slowest, largest) — The memory hierarchy pyramid. Speed increases and capacity decreases as you move toward the top. Image by Blog.Knatten.org, CC BY-SA 4.0.#

You can see the hierarchy in action from Python. The sys module reports how much RAM a Python object occupies, and time lets you measure how long operations take:

import sys
import time


def main() -> None:
    # A list of one million integers lives in RAM.
    numbers = list(range(1_000_000))
    print(f"RAM used by list: {sys.getsizeof(numbers):,} bytes")

    # Summing values already in RAM is fast.
    start = time.perf_counter()
    total = sum(numbers)
    ram_time = time.perf_counter() - start

    # Writing those values to a file and reading them back is much slower.
    with open("numbers.txt", "w") as f:
        f.write("\n".join(str(n) for n in numbers))

    start = time.perf_counter()
    with open("numbers.txt") as f:
        total = sum(int(line) for line in f)
    disk_time = time.perf_counter() - start

    print(f"RAM  time: {ram_time:.4f} s")
    print(f"Disk time: {disk_time:.4f} s")


if __name__ == "__main__":
    main()

Sample output (exact numbers vary by machine):

RAM used by list: 8,000,056 bytes
RAM  time: 0.0049 s
Disk time: 0.1268 s

Running this will show the disk read taking many times longer than the in-memory sum, even on a fast SSD. The gap is larger still on a traditional hard drive. Keeping frequently used data in RAM — rather than re-reading it from disk every time — is one of the most important performance principles in all of computing.

Data Representation#

Every piece of data a computer stores or processes — numbers, text, images, sound — is ultimately represented as bits: individual 0s and 1s. Eight bits make a byte. A single byte can represent 256 different values (0–255).

Humans usually write numbers in decimal (base 10, digits 0–9). Computers work internally in binary (base 2, digits 0 and 1). Two other bases appear constantly in computing:

Octal (base 8) — historically used in Unix file permissions.
Hexadecimal (base 16, digits 0–9 and A–F) — a compact shorthand for binary since one hex digit represents exactly four bits.

Python has built-in functions for converting between bases:

num = 42
print(f"Decimal:     {num}")
print(f"Binary:      {bin(num)}")
print(f"Octal:       {oct(num)}")
print(f"Hexadecimal: {hex(num)}")

Output:

Decimal:     42
Binary:      0b101010
Octal:       0o52
Hexadecimal: 0x2a

You can also convert back: int('0b101010', 2), int('0x2a', 16), and int('0o52', 8) all return 42. The prefix (0b, 0o, 0x) tells Python which base to use.

Horner’s Method: converting to any base

Python’s bin, oct, and hex only handle bases 2, 8, and 16. The classic algorithm for converting a decimal integer to any base uses repeated division: divide by the base, record the remainder as the next digit, and repeat until the quotient reaches zero. Reading the remainders in reverse gives the result. This is known as Horner’s method (or successive division).

For bases up to 16 we can represent each digit as a single character (0–9 then A–F). For larger bases there are not enough single characters, so we represent each digit as a decimal number separated by colons — exactly the way hours, minutes, and seconds are written for base 60.

def to_base(n, base):
    if n == 0:
        return "0"
    chars = "0123456789ABCDEF"
    negative = n < 0
    n = abs(n)
    result = []
    while n > 0:
        digit = n % base
        result.append(chars[digit] if base <= 16 else str(digit))
        n //= base
    result.reverse()
    digits_str = "".join(result) if base <= 16 else ":".join(result)
    return ("-" + digits_str) if negative else digits_str


def main() -> None:
    # Standard bases
    print(to_base(42, 2))     # binary
    print(to_base(42, 8))     # octal
    print(to_base(42, 16))    # hexadecimal
    print(to_base(-42, 2))    # negative number
    print(to_base(255, 16))   # one full byte in hex

    # Base 7
    print(to_base(42, 7))     # 6*7 + 0
    print(to_base(100, 7))    # 2*49 + 0*7 + 2
    print(to_base(-42, 7))    # negative in base 7

    # Base 60 - sexagesimal (Babylonian)
    print(to_base(42, 60))    # less than 60: single group
    print(to_base(90, 60))    # 1*60 + 30, like 1 min 30 sec
    print(to_base(3600, 60))  # 1*3600 + 0 + 0, like 1 hour
    print(to_base(3661, 60))  # 1*3600 + 1*60 + 1, like 1:01:01


if __name__ == "__main__":
    main()

Output:

Base 60 (sexagesimal) was invented by the Babylonians around 2000 BCE and is still with us today: 60 seconds in a minute, 60 minutes in an hour, 360 degrees in a circle (6 × 60). The colon-separated output mirrors the familiar hours:minutes:seconds notation — which is itself a base-60 representation. Base 7 is less common in practice but illustrates that the same algorithm works for any base with no changes to the code.

Boolean Logic and Logic Gates#

At the hardware level, the CPU is built from billions of tiny logic gates — each one performs a simple operation on bits. The fundamental gates are:

AND — output is 1 only if both inputs are 1.
OR — output is 1 if at least one input is 1.
NOT — inverts the input: 0 becomes 1, 1 becomes 0.
XOR (exclusive OR) — output is 1 if the inputs differ; 0 if they are the same.

All computation — arithmetic, comparison, branching — is ultimately built from combinations of these gates. Python exposes the same operations through its boolean operators:

a = True
b = False

print(f"a AND b:  {a and b}")
print(f"a OR b:   {a or b}")
print(f"NOT a:    {not a}")
print(f"a XOR b:  {a != b}")   # exclusive OR: true when inputs differ

Output:

a AND b:  False
a OR b:   True
NOT a:    False
a XOR b:  True

A truth table enumerates every possible combination of inputs and the corresponding output. Here is one for AND:

print(f"{'A':<6} {'B':<6} {'A AND B'}")
for a in [False, True]:
    for b in [False, True]:
        print(f"{str(a):<6} {str(b):<6} {a and b}")

Output:

A      B      A AND B
False  False  False
False  True   False
True   False  False
True   True   True

De Morgan’s Laws are two identities that relate AND, OR, and NOT. They come up constantly when simplifying logical conditions in code:

a, b = True, False

# NOT (a AND b)  ==  (NOT a) OR  (NOT b)
print(not (a and b) == (not a or not b))   # True

# NOT (a OR b)   ==  (NOT a) AND (NOT b)
print(not (a or b)  == (not a and not b))  # True

You will use boolean logic every time you write an if statement. The chapter on Simple Conditions covers this in depth.

What Is Software?#

Software consists of the programs and instructions that run on hardware. Software tells the hardware what to do, in what order, and how to respond to inputs.

There are three main categories of software:

System software — manages the basic operations of the computer.
- Operating systems: Windows, macOS, Linux, Android, iOS.
- Drivers: small programs that let the OS communicate with specific hardware (e.g., a printer driver or graphics driver).
Application software — programs that people interact with to accomplish tasks. Examples: web browsers, word processors, games, messaging apps, music players.
Utility software — supporting tools that maintain and optimize the system. Examples: antivirus tools, backup utilities, file compression, disk cleanup.

Programming Languages Across the Stack#

Not all software is written in the same language. Different layers of the stack call for different tools:

Assembly — one step above raw machine code. Specific to a CPU architecture. Used for bootloaders, firmware, and performance-critical inner loops. Gives complete control but is tedious and non-portable.
C — the dominant systems language since the 1970s. The Linux kernel, macOS core, and most of the internet’s infrastructure are written in C. Fast, portable, and close to the hardware — but the programmer manages memory manually.
C++ — extends C with object-oriented features. Used in operating systems, game engines, browsers (Chrome, Firefox), and real-time systems.
Java — compiles to bytecode that runs on the Java Virtual Machine (JVM), making programs portable across platforms without recompilation. Java manages memory automatically through garbage collection. It dominates enterprise backend systems and Android app development, and influenced languages like C# and Kotlin.
Rust — a modern systems language designed for memory safety without a garbage collector. Increasingly used in OS components, browsers, and infrastructure where C/C++ were previously the only options.
Ada — developed by the U.S. Department of Defense for safety-critical and mission-critical systems: avionics, defense, and medical devices.
Go — a modern, compiled language from Google designed for simplicity and performance. Its efficiency and built-in concurrency support have made it popular for networking, cloud infrastructure, and server-side systems programming.
Python — the language you are learning in this course — sits at the opposite end of the spectrum from assembly. It is interpreted, memory-managed, and highly expressive. Python trades raw performance for readability and development speed, making it ideal for data analysis, scripting, automation, and applications. Many systems are built with a fast C/Rust core and a Python layer on top.

How Hardware and Software Work Together#

The simplest model for understanding how a computer processes information is:

Input → Processing → Output

Input: data or commands entering the system (keypress, tap, voice command).
Processing: the CPU and RAM executing instructions and manipulating data.
Output: the result shown or sent back to the user (text on screen, sound, a printed page).

Here is a concrete walkthrough — pressing the “A” key on a keyboard:

Input: the keyboard’s hardware sends an electrical signal for that key.
Driver/OS: a keyboard driver translates the signal into a code the OS understands, then routes it to the active application.
Processing (CPU, RAM): the CPU runs the word processor’s code that inserts the letter. The document and cursor position are held in RAM.
Output: the OS updates the display, and the monitor shows the letter A.

The Role of the Operating System#

The operating system (OS) is the invisible coordinator that sits between applications and hardware. It plays three roles simultaneously:

Resource manager — schedules CPU time, allocates RAM, manages storage, and handles devices so programs do not conflict with one another.
Service provider — offers common services (file dialogs, network access, security) so each application does not have to build them from scratch.
Translator — applications do not talk directly to hardware. They ask the OS instead (“draw this window”, “save this file”), and the OS uses drivers to translate those requests into hardware signals.

Processes: Programs in Motion#

A program is a set of instructions stored on disk — it is inert until the OS loads and runs it. When that happens the OS creates a process: a running instance of the program with its own slice of RAM, its own open files, and a unique process ID (PID). The same program can produce many processes at once (think of opening several browser tabs).

Every process on a Unix system has a parent — the process that created it. When you run a Python script from the terminal, your shell is the parent. Python itself is the child process. You can inspect this directly:

import os

print(f"This script's PID:    {os.getpid()}")
print(f"Parent process's PID: {os.getppid()}")

Sample output (the exact numbers vary each run):

This script's PID:    48271
Parent process's PID: 48202

The OS is responsible for creating, scheduling, and eventually cleaning up every process on the system. When your Python script finishes — or crashes — the OS reclaims the memory and file handles that process was using.

You can also ask Python to start a new child process of its own using the subprocess module:

import subprocess

result = subprocess.run(["python3", "--version"], capture_output=True, text=True)
print(result.stdout)

Python 3.12.x

Here subprocess.run asks the OS to create a new process that runs python3 --version, waits for it to finish, and returns its output. This is exactly how the terminal works when you type a command — the shell is a process that spawns child processes for each command you run.

Types of Computer Systems#

So far we have described a single desktop or laptop. In practice, “a computer system” can take many forms:

Personal computers and workstations

The machines most students use for coursework: laptops, desktops, and tablets. One user, one machine, general-purpose tasks.

Servers and data centers

Powerful machines (or racks of machines) that run continuously and serve many users at once — hosting websites, databases, and applications. The computer in your pocket communicates with servers constantly.

Distributed systems

Multiple computers networked together that cooperate to solve a problem or provide a service. No single machine has all the data or does all the work. The internet itself is a distributed system.

Every machine on a network has an identity you can inspect from Python:

import socket
print(socket.gethostname())

Cloud computing

Renting computing resources — servers, storage, databases — over the internet rather than owning physical hardware. AWS, Google Cloud, and Microsoft Azure are the dominant providers. When you push code to GitHub or stream music, you are using cloud infrastructure.

High-performance computing (HPC) and clusters

Hundreds or thousands of processors working in parallel on a single large computation: weather forecasting, protein folding, physics simulations. These systems divide a problem into pieces and solve them simultaneously.

Quantum computers

Rather than bits (0 or 1), quantum computers use qubits that can exist in multiple states simultaneously. This makes certain problems — such as breaking encryption or simulating molecules — tractable in ways classical computers cannot match. Quantum computing is still an emerging field, but it represents a fundamental shift in how computation can be performed.

Note

The Python programs in this book run on a personal computer. But the skills you build here — writing clear, correct programs — transfer directly to servers, cloud functions, and distributed systems. The language is the same; only the scale changes.

Information and Communication Technology Literacy#

The ACM/IEEE curricula include a knowledge unit called ICT Literacy: Foundations that is relevant from the very first course. It describes the competencies every computing student should develop — not just programming skills, but the broader habits of a responsible technology user:

Fundamental concepts — understanding what hardware, software, networks, and the internet are and how they relate. This chapter covers the hardware and software side; networking appears later in the book.
Operational skills — being able to use common tools (terminal, text editor, file system, browser), manage files and directories, and navigate an operating system. The Terminal chapter addresses this directly.
Online communication — understanding email, forums, collaborative platforms (GitHub, shared documents), and how to use them appropriately in a professional and academic context.
Digital citizenship — awareness of the ethical, cultural, and legal issues around computing: intellectual property, privacy, and the social impact of technology. These themes recur throughout the course.
Online safety and security — using strong, unique passwords; enabling two-factor authentication; recognizing phishing; practicing safe browsing. These are not optional extras — they are professional baseline skills.
Problem-solving with ICT — using search effectively, reading documentation, troubleshooting hardware and software issues methodically. Learning to find answers is as important as knowing answers.

Note

These competencies are harder to grade than code — but they matter just as much. A programmer who writes correct Python but falls for a phishing email, ignores licensing, or cannot navigate a terminal is not yet a complete computing professional.

Metaphors for Hardware and Software#

Concrete analogies can make these abstractions easier to remember:

Body and mind: hardware is the body (organs, muscles); software is the mind (thoughts, decisions, instructions). Neither is useful without the other.
Kitchen and recipe: hardware is the kitchen (stove, pots, utensils); software is the recipe (steps and instructions). The same kitchen can produce many dishes by following different recipes.
Instruments and sheet music: hardware is the instruments; software is the score. Change the music, and the same instruments produce a different performance.

Exercises#

List five hardware components found in a smartphone. For each one, identify whether it is an input device, output device, processing unit, or storage unit.
Classify each of the following as system software, application software, or utility software: macOS, Spotify, an antivirus scanner, a printer driver, a web browser, a disk defragmenter.
Trace the Input → Processing → Output steps that occur when you tap the “Play” button in a music app.
In your own words, explain what an operating system does. Use the traffic-cop or translator metaphors if they help.
Draw the memory hierarchy as a triangle with the fastest/smallest storage at the top. Label each level with an approximate size (bytes, kilobytes, gigabytes, terabytes) and a representative access time.
Run the memory hierarchy Python example from this chapter. Record the RAM time and disk time. How many times faster is RAM access on your machine?
Run the process identity example (os.getpid() / os.getppid()). Open your operating system’s process viewer (Activity Monitor on macOS, Task Manager on Windows, top on Linux) and find Python in the list. Does the PID match?
Classify each of the following as a personal computer, server, distributed system, or cloud service: your laptop, Gmail, a university’s web server, a weather forecasting supercomputer, Netflix.
Convert 42 to binary, octal, and hexadecimal by hand using repeated division, showing each step. Then verify your answers using Python’s bin(), oct(), and hex().
Call to_base(42, b) for every base b from 2 to 16 and print the results. What do you notice as the base increases?
Write a from_base(s, base) function — the inverse of to_base — that converts a string representation back to a decimal integer. It should handle negative numbers (strings starting with -) and bases up to 60. Test it by verifying that from_base(to_base(n, base), base) == n for several values of n and base.
Use to_base to express 7,384 seconds in base 60. Then verify the result by computing the hours, minutes, and seconds manually (7384 // 3600, (7384 % 3600) // 60, 7384 % 60). What familiar notation does the base-60 output resemble?

Write a Python loop that prints the complete truth table for OR and for XOR across all four input combinations. Then verify both of De Morgan’s laws hold for every combination:

for a in [False, True]:
    for b in [False, True]:
        assert not (a and b) == (not a or  not b)
        assert not (a or  b) == (not a and not b)

Implement nand(a, b) as not (a and b). Then express AND, OR, and NOT using only nand:
- NOT a is nand(a, a)
- a AND b is nand(nand(a, b), nand(a, b))
- a OR b is nand(nand(a, a), nand(b, b))
Verify each identity holds for all four input combinations. This property — that every logical operation can be built from NAND alone — is why real CPUs are constructed almost entirely from NAND gates.
Extend to_base to raise a ValueError with a descriptive message if base is less than 2 or greater than 60. Test that the error is raised correctly for base=1 and base=61.

References

[DeanNorvig]

Jeff Dean and Peter Norvig, Latency Numbers Every Programmer Should Know, Google, 2012. Widely circulated reference; canonical version maintained at https://gist.github.com/jboner/2841832

[HennessyPatterson2024]

John L. Hennessy and David A. Patterson, Computer Architecture: A Quantitative Approach, 7th ed., Morgan Kaufmann, 2024.

Hardware and Software

Contents

Hardware and Software#

What Is Hardware?#

The Memory Hierarchy#

Data Representation#

Boolean Logic and Logic Gates#

What Is Software?#

Programming Languages Across the Stack#

How Hardware and Software Work Together#

The Role of the Operating System#

Processes: Programs in Motion#

Types of Computer Systems#

Information and Communication Technology Literacy#

Metaphors for Hardware and Software#

Exercises#
